KRILL WEBSITE: http://www.krill-model.com



AreS XL (KRILL - SEBART COOPERATION)

Su 2.6 mt


AreS XL 3D jet kit is a joint product between KRILL Aircraft and Seba Silvestri with the goal of offering a big sport jet kit with ultimate flying characteristics for both precision and 3D aerobatics. Size is set not to exceed European weight limit 25 kg – which means the jet is ready to fly with fuel+smoke.
To achieve this, they designed an extremely light frame (empty less than 9000 grams) with huge ailerons and flaps on central hinges.
Flaps are possible to operate not only as a flaps (flaps move in positive deflection), but by mixing with ailerons as an additional surface for ailerons. Fuselage has a slim, flat and tall shape for great stability during knife edge flight. Elevators and rudder use central hinges as well.
Frame is very light but strong enough for extreme maneuvers at medium speeds. For easier transportation you can dismantle fuselage into two pieces, dividing line is behind wings line and turbine. Wings, elevators and fin with rudder are removable as well.
Kit is designed to be powered by jet turbines with thrust from 18 kg for sport flying, at least 30kg for 3D flying with vectored jet pipe. The jet is set up for Electron retracts. Front gear door is operated by linear actuator controlled from retract controller or directly from receiver, hinges of front doors are installed.
Special designed Kevlar tanks for kerosene and smoke are available, with tanks holder installed inside fuselage. Attaching them is very easy with 4 screws, no additional work is needed.
Thrust pipes are offered in 3 sizes and one with vectoring.






Ap. alare: 270 cm
Lungh. 330 cm
Peso a secco: ~20kg
RTF con turbina P180 RX
Turbina: da P180RX in su
Radio: 9 canali o sup.

Il modello può essere equipaggiato con:
1 o 2 servi per alettone
1 servo per ogni flap
1 servo per direzionale
1 servo per ogni elevatore
Tutti servi minimo 25Kg
Tutte la superfici mobili hanno sedi forate pronte per le squadrette.


DISPONIBILE

Per ordini scaricare il foglio in EXCEL
QUI

ALTRE IMMAGINI




Wing Span: 106.29 in
Length: 129.92 in
Dry Weight: 46-51 lbs
Turbine: 180N and Up
Radio: 9+ Ch.

Kit should be equipped with 1 or 2 servos for each aileron
1 servo for each flap
1 servo for rudder
1 servo for each elevator
All servos must be at least 25 kg
All control surfaces are pre drilled with holes for Gabriel horns that come with the kit.

IN STOCK

To place an order
download order form from HERE

MORE IMAGES


.






Differenti colorazioni disponibili sul sito di KRILL Aircraft
More paint schemes on KRILL Aircraft website:


www.krill-model.com/katalog/models/ares-jet/ares-xl-3300.html




Sukhoi 29S KRILL


Kit ARF quasi pronto al volo, completo di tutti gli accessori, modello progettato per l'acrobazia maxi.

Kit ARF almost ready to fly, with all accessories. Designed for maxi aerobatics competitions.


Ap. alare 299 cm
Lunghezza 270 cm
Peso kit 8,50 kg
Per motori:
150/170cc benzina

Scarica il LISTINO PREZZI
completo in .pdf


DISPONIBILE
ALTRE IMMAGINI


Il modello di Seba pesa 18,50 kg e monta un Mintor 220cc



Wing Span 299 cm
Lenght 270 cm
Kit weight 18.74 lbs
For engines:
150/170cc gas

Download full PRICE LIST
.pdf document


IN STOCK
MORE PICTURES

Seba plane weights 18,50 kg powered by Mintor 220cc






ALTRE IMMAGIN/MORE PICTURES
